AFrame Pro: Frame Analysis
iOS Universel / Productivité
Professional 2D Frame Structural Analysis
AFrame Pro is a professional structural engineering application for analyzing two-dimensional frame structures using the Direct Stiffness Matrix Method.
Designed for structural engineers, civil engineers, students, educators, and researchers, AFrame Pro combines a modern interface with powerful engineering calculations to help you create, analyze, and understand structural behavior anywhere.
Design Structural Frames
Create and edit structural models quickly with an intuitive graphical interface.
• Interactive 2D frame editor
• Multi-story and multi-bay frame generation
• Grid frame templates
• Node editing
• Member editing
• Support definitions
• Point loads
• Distributed loads
• Moment loads
• Pan and zoom controls
Powerful Structural Analysis
Analyze structures using the Direct Stiffness Matrix Method.
Features include:
• Global stiffness matrix assembly
• Local stiffness matrices
• Coordinate transformation matrices
• Joint displacements
• Member end forces
• Support reactions
• Equilibrium verification
• Linear elastic analysis
Material & Section Libraries
Manage reusable engineering properties.
• Material library
• Elastic modulus
• Cross-sectional area
• Moment of inertia
• Multiple material definitions
Engineering Reports
Generate comprehensive analysis reports including:
• Equilibrium checks
• Stiffness matrices
• Transformation matrices
• Member stiffness calculations
• Support reactions
• Member forces
• Displacements
• Calculation summaries
Structural Diagrams
Visualize structural behavior with:
• Shear Force Diagrams (SFD)
• Bending Moment Diagrams (BMD)
• Deflected Shapes
• Reaction forces
• Applied loads
Professional PDF Export
Create engineering-quality PDF reports suitable for:
• Design documentation
• Engineering review
• University assignments
• Project records
• Client presentations
Multiple Unit Systems
Supports both SI and US Customary units with automatic unit handling.
Ideal For
• Structural Engineers
• Civil Engineers
• Engineering Students
• University Professors
• Researchers
• Engineering Consultants
Whether you're solving classroom problems, checking structural behavior, or preparing professional engineering documentation, AFrame Pro delivers accurate analysis in a clean, modern workflow.
Quoi de neuf dans la dernière version ?
• Improved Analysis Reports
Equilibrium checks are now cleaner and easier to read, with tiny numerical round-off values hidden from the equations.
• Cleaner Moment Checks
Moment equation terms with a zero displayed lever arm are no longer shown.
• General UI and Unit Formatting Improvements
Report views, unit display, and number formatting have been polished for a smoother workflow.
